Frequency Range

VHF:136-174MHz UHF: 400-470MHz

Number Of Channels

512

Channel Spacing

25/12.5KHz

Operating Voltage

7.4V

Standard Battery

2000mah (lithium ion)

Battery Average Working Hours (5-5-90 Working Cycles)

Analog / Digital: 13/17 hours

Frequency Stability

±1.5 PPM

Operating Temperature Range

-20℃~+55℃

Antenna Impedance

50Ω

Dimensions (H x W x D)(Without Antenna)

119 x 55 x 34mm

Weight (Including Antenna And Battery)

280g

Output Power

VHF: 5.0W/1.0W UHF: 4.0W/1.0W

Modulation (Analog)

11KΦF3E@12.5KHz 16KΦF3E@25KHz

Modulation (Digital)

12.5KHz Data and voice 7K60FXW. Data only 7K60FXD

Clutter And Harmonics

-36dBm<1GHz -30dBm>1GHz

Signal To Noise Ratio

40/45dB

Audio Distortion

≤3%

Modulation Limit

±2.5@12.5KHz；±5.0@25KHz

Audio Response(300 ~ 3000HZ)

+1to-3dB

Digital Vocoder Type

AMBE++

Digital Protocol

ETSI-TS102361-1.-2.-3

Sensitivity (Simulation)

≤0.30/0.20µV

Sensitivity (Number)

≤0.22µV/BER5%

Adjacent Channel Selectivity

60/70dB

Intermodulation

65dB

Spurious Response Suppression

70dB

Signal To Noise Ratio

40/45dB

Audio Output Power

1.0W

Audio Distortion

≤3%

Audio Response

+1~-3dB

Conduction Emission Miscellaneous

<-57dBm
