Module Type

RTOS Cat.1

Standard Battery Capacity

3000mAh

Network Version A (Region: Latin America)

LTE-FDD: B2/3/4/5/7/8/28/66

Battery Standby Time

80 Hours

Network Version B (Region: Europe)

LTE-FDD: B1/3/5/7/8/20/28 LTE-TDD: B38/40/41

Operating Voltage (V)

3.7V

Network Version C (Region: Asia)

LTE-FDD: B1/3/5/8 LTE-TDD: B34/38/39/40/41

SIM Card Size

1 Nano SIM

Dimensions (H X W X D)

90 x 53 x 34mm

Weight (With Standard Battery and Belt Clip)

185g

Operating Temperature Range

-10℃ ~ +55℃

Antenna Impedance

50Ω

Audio Distortion

≤5%

Audio Output Power

2W
